Pro-gm6.4b

SKU
PRO-GM6.4B
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
4 Ohm
RMS Power Handling
140W
MAX Power Handling
480W
Sensitivity (1w/1m)
93dB
Frequency Response
100Hz-6.3KHz
Recommended HI Pass Crossover
120Hz
Pair or Single
Single
Grill Included
No

MOTOR

Voice Coil Diameter
1.5" / 38.1mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Paper
Dust Cap Material
N/A
Bullet Material / Color
Red Aluminum
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Matte Black
Magnet Material
Ferrite
Magnet Weight
23 oz

THIELE & SMALL PARAMETERS

Equivalent Volume (Vas)
4.9L / 0.173ft3
Excursion (one way) (Xmax)
N/A
Free Air Resonance (Fs)
113HZ
Mechanical Factor (Qms)
11.955
Electrical Factor (Qes)
0.705
Total Factor (Qts)
0.666
Mechanical Mass (Mms)
9.862g
Mechanical Compliance (Cms)
0.198mm/N
BL Factor (BL)
5.75
Voice Coil Inductance (Le)
0.453mH
Cone Area (Sd)
132.73cm2
DC Resistance (Re)
3.3 ohm

MEASUREMENT

Overall Diameter
6.57" / 167mm
Overall Depth
2.7" / 69mm
Front Mount Baffle Cutout
5.7" / 145 mm
Mounting Depth
2.5" / 64mm
Motor Diameter
4.33" / 110mm
Gross Single Unit Weight (lb)
4
Single Unit Box Dimensions W x L x H (Inches)
7.3 x 7.3 x 3.25
Quantity of Units in Master Carton
8
Gross Master Carton Weight (lb)
32
Master Carton Dimensions W x L x H (Inches)
15.25 x 15.25 x 7.5
